LFA130 High Capacity Air Cleaner for Central Pneumatic Networks
| MOQ: | 1 |
| Price: | 25USD/PCS |
| Standard Packaging: | Plastic bag-box-cartons/pallets or Custom options |
| Delivery Period: | 30 days |
| Payment Method: | T/T |
| Supply Capacity: | 1000+ pcs |
| EXOMIST Model | EXOMIST063013 |
|---|---|
| Original Filter Brand | YUKA |
| Original Model9 | LFA130 |
| Precision / Residual oil amount | 25 μm/5 ppm |
| Processing capacity | 25.0 Nm³/min |
| Working Temperature | 1.5 ~ 80℃ |
| Working Pressure | 0.1 ~ 2.0Mpa |
| Media | Micro fiberglass |
| End Caps | Engineering plastic |
| Seal | Buna-N |
| Weight (including packaging) | 1.1kg |
| Size packaging(cm) | 38*12.5*12.5 8# |
| Dimensions(mm) | D:126±1 H:370±2 |
| Country of Origin / HTS Code | CHINA / 8421999090 |
Maximum Flow Coarse Pre Filter Element - Model LFA130
The LFA130 is the highest flow coarse pre filter cartridge in the YUKA LFA series, engineered for central compressed air systems with extreme volume demands. It captures solid contaminants down to 25 microns including rust, scale, and dust, while reducing residual oil content to 5 ppm. The micro fiberglass depth media provides high dirt holding capacity with very low flow resistance.
Rated at 25.0 Nm3/min, this element supports main plant headers serving entire production facilities, multiple high consumption laser cutting tables, large electronics assembly halls, and heavy sandblasting systems running continuous shifts. Clean pressure drop remains ≤0.01 bar, delivering 5-7% energy savings over the 8000 hour service life. Weight is 1.1 kg.
The LFA130 requires filter housings with appropriate clearance for its size (dimensions not specified in technical sheet). Engineering plastic end caps and Buna-N seals ensure reliable operation from 1.5 to 80°C and pressures up to 2.0 MPa.
- 25 micron coarse filtration - Traps rust scale and large debris
- 5 ppm oil mist reduction - Acceptable for general industrial air
- Micro fiberglass depth media - High capacity with low restriction
- 25.0 Nm3 min flow rate - Highest in LFA series, supports entire plants
- 0.01 bar pressure drop - Saves 5-7% compressor energy over 8000 hours
- 8000 hour service life - Maximum intervals for critical infrastructure
- 1.1 kg weight - Manageable for large cartridge size
- Buna-N seals - Reliable from 1.5 to 80°C up to 2.0 MPa
- Laser cutting assist air - Coarse pre filtration before fine filter
- Electronics SMT assembly - Removes large particles from air lines
- Sandblasting cabinets - Protects nozzles from rust and scale
- Industrial pneumatic tools - Extends tool life with clean air
- Point of use pre filtration - First stage before sensitive equipment
- 24 hour dispatch - Stock items ready for immediate shipment
- Low MOQ - One piece accepted for trial and evaluation
- OEM drawing service - Custom end caps seals or packaging available
- Factory direct pricing - Competitive for bulk orders of 1000+ pieces monthly
- Full compliance - CE RoHS and ISO8573-1 certification provided
